LAKSA

About the project

This repo contains LAKSA, the compiler infrastructure component of the MYRTUS project, which funds this work. All analysis, optimization, and backend code generation for LAKSA targets flow through the dialects and passes defined here.

The compiler is built on top of MLIR, which allows each stage of the pipeline to be expressed as a dialect lowering, from high-level dataflow graph descriptions down to target-specific output. Each dialect in this project represents one layer of that pipeline.

The DFG dialect is a reimplementation of Feliix42/dfg-mlir.

The paper describing this project has been accepted at CASES’26. The proceedings aren’t out yet (a link to the paper will be added here later).

Related projects

laksa-hls-kria-driver is a companion Linux kernel driver for deploying LAKSA-generated HLS kernels on Xilinx Kria boards (tested on the KV260, ZynqMP). It exposes /dev/laksa, a character device through which userspace programs manage the DMA buffer lifecycle and drive kernel execution over AXI Lite via ioctl calls, with no kernel recompilation needed when switching between HLS designs.

Development Environment (Nix)

This repo ships a Nix flake that provides a complete dev shell with LLVM/MLIR, cmake, ninja, mold, doxygen, gurobi, and the Python toolchain already on PATH, with LLVM_DIR, MLIR_DIR, LLVM_EXTERNAL_LIT, PYTHONPATH, GUROBI_HOME, and GRB_LICENSE_FILE set automatically:

nix develop

If you use direnv, direnv allow will load the shell automatically via the included .envrc. With the shell active, build.sh detects the toolchain env vars and configures/builds directly, no arguments needed:

bash build.sh

Build on Ubuntu 24.04 (no Nix)

Built and tested against llvm-23.1.2. Both x86_64 and aarch64 are supported; build.sh reads uname -m and picks the matching Gurobi build (linux64 / armlinux64) itself.

Outside the Nix shell, build.sh installs the system packages, fetches LLVM/MLIR and Gurobi, and sets up the Python venv, so it needs no arguments here either:

bash build.sh

The prebuilt LLVM/MLIR tarball is about 700 MB and lands in build/, so the first run takes a while.

Run in Docker

Images for linux/amd64 and linux/arm64 are published to the GitHub Container Registry. main publishes latest, every other branch publishes under its own name:

docker pull ghcr.io/tud-ccc/laksa:latest

The image carries the four tools on PATH and the mlir_laksa bindings importable from both the venv and the system interpreter. It starts in /work, so mount your working directory there:

docker run --rm -it \
    -v "/PATH/TO/YOUR/WORK:/work" \
    -v "/PATH/TO/gurobi.lic:/opt/gurobi/gurobi.lic:ro" \
    ghcr.io/tud-ccc/laksa:latest

The license mount is not optional for that command: the pragma DSE pass in the HLS pipeline is Gurobi-backed. Without it the entrypoint warns and only the passes that do not need Gurobi still run.

Because of --rm, changes made inside the container are gone once it exits, unless they are in a mounted directory.

To build the image from this repository instead:

docker build -t laksa .

Gurobi license

A license is required however you build, and nothing here creates one for you. build.sh only checks that the license file exists and warns if it does not; the build still succeeds without it, but anything using Gurobi fails at runtime.

Put your license at $HOME/.gurobi/gurobi.lic, which is where both the Nix shell and build.sh look by default. To keep it somewhere else, point GRB_LICENSE_FILE at it before building:

export GRB_LICENSE_FILE=/path/to/gurobi.lic

Installing

cmake --install build --prefix /where/you/want

This gives you bin/ with the four tools, include/ with the headers and the TableGen output merged into one tree, lib/ with the static libraries, and lib/cmake/laksa/ so that a downstream CMake project can do:

find_package(LAKSA REQUIRED)
target_link_libraries(my-tool PRIVATE LAKSA::DFGIR)
target_include_directories(my-tool PRIVATE ${LAKSA_INCLUDE_DIRS} ${MLIR_INCLUDE_DIRS})

Pass --component to install one piece on its own: LAKSATools, LAKSAHeaders, LAKSALibraries, LAKSADevelopment, or LAKSAPythonModules.

The Python package

The bindings are a pip package, built from this repository:

pip install /path/to/laksa

While working on the bindings themselves, cmake --build build --target install-python-package does an editable install instead, so edits to the .py sources under python/mlir_laksa/ take effect without reinstalling.

cmake --install is not a third way to do this, and nothing it writes is a pip source directory. It copies the package to <prefix>/mlir_laksa, which no interpreter looks in, as a staging copy for packagers to relocate. That path is what it is because pip sets the install prefix to the wheel’s platlib directory, so the package has to sit at the root of the prefix.

Run the tests

The .mlir FileCheck test suite under test/ is run with:

cmake --build build --target check-laksa-mlir

Using the Python bindings

See python/examples/ — it mirrors test/’s layout, with one .py file per .mlir test rebuilding the same IR via the Python bindings and running the same pass(es). Start there for runnable references on constructing ops and invoking passes.

cmake --build build --target check-laksa-python

This target verifies every example still matches its .mlir counterpart, depending on install-python-package to rebuild and reinstall first.

Build the documentation

The Doxygen and Sphinx documentation is found under build/docs/sphinx/index.html:

cmake --build build --target build-laksa-doc

The target installs docs/requirements.txt into the configured Python first.

Compiling a design

ladle is the driver. It dispatches to laksa-opt and laksa-translate, so everything below can also be done by hand with those two.

Run one pipeline and one translation:

ladle input.mlir -p convert-to-emithls -t emithls-to-cpp -o main.cpp

--hls does the whole thing instead. It lowers the input twice and writes every artifact a board deployment needs below one directory:

ladle input.mlir --hls -o out_dir

out_dir/
├── hls.mlir            the design, lowered to the EmitHLS dialect
├── ref.mlir            the same input lowered to emitc instead
├── hw/                 what the build host needs
│   ├── main.cpp        Vitis HLS input
│   ├── run_hls.tcl     C synthesis and IP export
│   ├── run_vivado.tcl  block design, synthesis, implementation, bitstream
│   └── build.sh        runs both, extracts <design>.bit from the XSA
└── app/                what the board needs
    ├── app.h           buffer sizes and AXI-Lite register offsets
    ├── app.c           userspace driver, talks to /dev/laksa
    ├── app.dtsi        device tree overlay
    ├── ref.h           the scalar reference
    ├── ref.c           compares the board's output against ref.h
    └── run.sh          loads the design, runs it, checks it

Every hw/ artifact and most app/ ones are translated from hls.mlir. ref.h and ref.c come from ref.mlir, which is the same input lowered without any of the HLS-specific restructuring, so the reference computes what the design is meant to compute rather than a re-derivation of what it does.

Each step prints what it is producing, so a failure names the artifact that could not be written.

--num-bram and --num-dsp give the pragma DSE a different resource budget than the default one of convert-to-emithls (by default 288 BRAMs and 1248 DSPs):

ladle input.mlir --hls --num-bram=144 --num-dsp=600 -o out_dir

Running a design on the board

hw/ and app/ are independent and can live on different machines.

On the build host, with the Xilinx tools sourced:

# In hw
./build.sh

This runs vitis-run --mode hls, then vivado -mode batch, then extracts <design>.bit from the exported XSA. It takes a while. <design> is the name of the design’s top function, main_top for the examples under examples/.

<design>.bit is the one file the board needs out of hw/. Put it in the app/ directory, next to app.c, and deploy that directory to the board however you like; run.sh looks for the bitstream beside itself and nowhere else.

On the board, which needs laksa-hls-kria-driver loaded and its laksa.h installed:

# In app
./run.sh

run.sh compiles the overlay with dtc, loads it and the bitstream with fpgautil, builds app and ref, fills any missing input<n>.bin with random bytes, runs the design, and compares what it wrote against the reference:

<design>: ran on the FPGA in <time> ms
reference: ran on the CPU in <time> ms
output0.bin: all <num> elements match the reference

Both times cover the kernel alone. app takes its from asserting ap_start to seeing ap_done, which leaves out copying the buffers to and from the device, and ref takes its around the call to the scalar reference, which leaves out reading the .bin files and comparing them.

Mismatches are reported per element, with the index into the output buffer, and ref exits non-zero.

The .bin files are raw dumps of the DMA buffers with no header, one input<n>.bin per argument the kernel reads and one output<n>.bin per argument it writes. Dropping in your own inputs of the right size is all it takes to run real data; the sizes are in app.h.
